Highlights
• High-grade automotive tuner
• FM (RDS), AM (MW, LW)
• DAB+ tuner
• Twin-Encoder concept for comfortable selection of folders/files
• Playback formats: MP3, WMA
• Fast reading of USB, SD media
• Different display modes (ID3 tags, folder/file name, duration, time, all)
• Media: USB, SDHC, SD
• iPod, iPhone control (via USB)
• 9-digit display
• Bluetooth integrated (HFP, A2DP, PBAP, AVRCP)
• Integrated microphone
• Front USB (standard A-type)
• SDHC card reader (behind release panel)
• Front aux-in
• Steering wheel remote control (programmable)
• 4 x 50 watts max.
• 4-channel preamplifier
• Separate sub-out
• Sound presets (rock, pop, classical)
• X-Bass
• White button illumination
• Release panel
• Remote control (included)
DAB features
• DAB/DAB+
• Station memory: 15 (DAB 1, 2, 3)
Analogue radio
• Tuner type: high-grade RDS automotive tuner
• Frequency bands: FM1, 2, AM, LW
• Radio Data System (RDS): Alternative Frequency (AF), Clock Time (CT), Enhanced Other Networks (EON), Programme Service Name (PS), Programme Types (PTY), Regional Programme (REG), Traffic Announcement (TA), Traffic Programme (TP)
• Station memory: 25
• Sensitivity: lo/dx
• Interference suppression: yes
• Supported version: Bluetooth 2.0 with DER
• Supported profiles: HFP, PBAP, A2DP, AVRCP
• Audio streaming: yes
• Hands-free phone calls: via microphone and speaker
• Hands-free volume: variable
• Microphone: integrated + rear connection
• Access to phone book: yes (up to 1000 contacts per mobile phone)
Media player
• Playback formats: MP3, WMA
• Title display: ID3 tag (version 2), folder/file
• Folder and file selection: yes (LIST button/without interruption)
• iPod, iPhone control: yes (via USB)
• Android MP3 control: yes (with Android operating system 2.3 and newer)
• Fast list browsing: yes (via second encoder)
• Display modes: yes (file/folder name, artist, album, title, duration, time, all)
• Display texts: file up to 50 digits/ID3 up to 30
General
• Twin-Encoder concept:
- Left for volume and mute
- Right exclusively for browsing, phone book, tuner and menu
• Software update: via USB
• Variable scan time: yes
• Confirmation beep: yes (on/off)
• Control panel type: release panel
• Colour of panel/decorative ring: black/black
• Encoder/button illumination: blue/white
• Permanent storage after loss of power: yes (settings and presets)
• Demo mode: yes
• Weight (kg): approx. 1.6
• DAB window aerial: yes
• Panel case: yes
• IR remote control: yes
• Spacer screw/bolt: yes
• Dimensions (W x H x D): 178 x 50 x 120 mm
